The FRC-type triple unit consists of an Festo Type FC Frl regulator and an LOE-type lubricator, which can be ordered separately. The water separator can filter liquid oil, condensate, and impurities in the air. For special applications, the 5μm filter cartridge can be easily replaced with the standard 40μm filter cartridge. Even with fluctuations in input pressure and compressed air consumption, the pressure regulator can ensure that the set working pressure remains stable. The lubricator can evenly spray oil mist into the filtered air, with the oil mist volume proportional to the air flow rate. It can continuously add oil without stopping the air and adjust the drip oil amount by adjusting the screw. Typically, 1-12 drops per 1000L of air are sufficient.
|
FRC TECHNICAL PARAMETER |
||||||||
|
SPECIFICATION |
MINI |
MIDI |
MAXI |
|||||
|
Working medium |
AIR |
|||||||
|
Structural features |
Sintered with water separator filter: MINI/MIDI:Diaphragm valve MAXI:Piston reducing valve Oil mist automatic variable throttling type |
|||||||
|
Installation method |
Tubular or bracket installation |
|||||||
|
Installation position |
vertical direction ± 5° |
|||||||
|
Connection size |
G1/8 |
G1/4 |
G3/8 |
G3/8 |
G1/2 |
G3/4 |
G3/4 |
G1 |
|
Standard niminal flow rate LFR..(-A) |
700 |
1000 |
1200 |
2000 |
2600 |
2600 |
7000 |
8000 |
|
Standard niminal flow rate LFR..7...(-A) |
800 |
1300 |
1500 |
2500 |
2800 |
2800 |
8500 |
8700 |
|
Standard niminal flow rate LFR..5M..(-A) |
600 |
850 |
1050 |
1700 |
1800 |
2100 |
6500 |
7200 |
|
Input pressure |
Manual drain valve:1-16 bar |
|||||||
|
Input pressure |
Automatic drain valve:1.5-12 bar |
|||||||
|
Working pressure |
0.5-12 bar /0.5-7 bar |
|||||||
|
Minimum fogging flow rate |
3 I/min |
6 I/min |
10 I/min |
|||||
|
Filter precision |
40μm/5μm |
|||||||
|
Max limeset capacity |
22ml |
43ml |
80ml |
|||||
|
Medium Temperature |
0-60℃ |
|||||||
|
Material: |
Material: Shell: Die cast zinc; Filter cup and oil cup; PC metal protective cover: aluminum alloy; Sealing: nitrile rubber; Pressure regulating handwheel: POM |
|||||||
