JM322 Series Mechanical Button Control Valve 3 Way

Model:JM322

OLK is a professional JM322 Series Mechanical Button Control Valve 3 Way manufacturers and suppliers in China, you can rest assured to wholesale and customized JM322 Series mechanical valve from our factory and we will offer you the best after-sale service and timely delivery.

Send Inquiry

Product Description

OLK JM322 series mechanical valve is 2/3 way valve.JM322 feature advacned desivn and manufacturing processes,be able to controlling the direction of gas.To improve pneumatic systems efficiency and save energy consumption.

Symbol:

Ordering code
JM	32	2	R
JM TYPE MECHANICAL VALVE	POSITION NO:	PORT SIZE:	BUTTON TYPE
	32:2 POSITION 3 WAY	2:G1/4	Blank:Basic Type (JM322)
			R:Roller Type (JM322R/JM-07)
			PP:Flat Button (JM322PP)
			PPL:Raised Button (JM322PPL)
			PB:Large Round Button (JM322PB/JM-06A)
			EB:Locking Button (JM322EB/JM-06)
			TB:Selector Knob (JM322TB/JM-05)
			LB:Selector Knob (JM322LB)

The OLK JM322 Series mechanical valve has a G1/4 interface thread. The button types available are:

- Basic Type (JM322)

- Roller Type (JM322R/JM-07)

- Flat Button (JM322PP)

- Raised Button (JM322PPL)

- Large Round Button (JM322PB/JM-06A)

- Locking Button (JM322EB/JM-06)

- Selector Knob (JM322TB/JM-05)

- Selector Knob (JM322LB)

JM322 SERIES Mechanical button control valve 3 way General parameters

working medium	Air (filtered through a filter over 40μm)
Action	External Control Direct Action
Port diameter	G1/4
number of positions	Two position three way
lubricating	unnecessary
Working pressure range MPa(psi)	0∼0.8(0~114)
Guaranteed pressure resistance	1.5MPa (215psi)
Working temperature °C	-5∼60
Body material	aluminum alloy
